MOTOR DATA

Model

V180F-A

Power

0.18kw/0.23hp

Max flow

133L/min

Max head

7m

Outlet

40mm

GW

8.5kg

Dimensions

18.5*18*36.5cm/box

Free accessories

NO

warranty

One year

TECHNICAL DATA

Fluid temperature range

0-40°C

Max working pressure

4bar

Single phase

220V/50-60HZ

110V/60HZ

Max deep is allowed in water from the center of impeller

5m

Trans medium PH

4-10

Kinematics viscosity of trans medium

0.7-23mm2/s

Density of trans medium limit

1200kg/m2

MOTOR

Degree of protection

IP68

Insulation class

B

MATERIALS

Cap

Cast iron

Motor body

Stainless steel

Basement

Cast iron

Impeller

Cast iron

Shaft

45# steel
