This tester is applied to integrated test varieties of compressor stator in refrigerator, air conditioner and heater etc. Its LCD displays all technical data which obtained by industrial control computer, which check and verify the quality of testing stators.

Main specification:
1. Hi-pot
(1) Testing voltage: AC100~5000V
(2) Testing range: 0.5/1/2/2/10Ma
(3) Testing precision: +/-0.5%
(4) Testing position: between winding and core
2. Insulation resistance
(1) Testing voltage: DC500V
(2) Testing range: 10-500mΩ
(3) Testing precision: +/-1.0%
(4) Testing position: between winding and core
3. DC resistance
(1) Testing voltage: 1.8/18/180mA
(2) Testing range: 0.01-1.999Ω
(3) Testing precision: +/-0.5%
(4) Testing position: inter-windings
4. Inter-turns insulation
(1) Testing voltage: DC100-5000V
(2) Testing range: 0-100
(3) Testing precision: +/-1.0%
(4) Testing position: each winding
5. Reverse winding test
(1) Testing voltage: 10-200VDC
(2) Testing range: 0-100
(3) Testing precision: +/-1.0%
6. Rotation direction
(1) Testing voltage: 0-250V
(2) Testing range: CW, CCW, stop
(3) Testing position: main phase/high gear
7. Flash-over test
(1) Testing voltage: AC100-5000V
(2) Testing range: 0.5/1//2/5/10mA
(3) Testing precision: +/-0.5%
(4) Testing position: between winding and core
