Stator Paper Forming And Cutting Machine ND-LGJ-1

Stator paper forming and cutting machine is suitable for two pole stator insulation paper forming and cutting. Our Stator paper forming and cutting machine is easy to operate, and change tooling is very simple. It also can be achieved if you need the paper with punching hole.

Technical parameter:
Stator I.D range: 30--55mm
Max stator O.D range: 50--95mm
Stack length : 5--80mm
Paper width: less than 130mm
Paper thickness: less than 1mm
Slot number: 2 slots
Productivity: 4 pcs/second
Air pressure:0.4--0.7Mpa
Machine weight: 110Kgs
Machine dimension: 490X790X1200mm
