Nominal gross pressure |
12000Kn |
Direction of feeding plate |
Horizontal |
Layer Counting |
1 Layer |
Distance between hot platens |
300mm |
Numbers of hot platens |
2 pcs |
Dimension of Hot Platens |
2700×1400×100mm(up) 2700×1400×120mm(down) |
Numbers of Cylinder |
6 Pcs |
Diameter of Cylinder |
Φ320mm |
Stroke of Cylinder |
300mm |
Pressurization |
≤25Mpa |
The Position of Cylinder |
up |
Empty Closing Time |
about 4-5 s |
Numbers of Lift Cylinders |
4pcs |
Diameter of Cylinder |
Φ60mm, Φ30 |
Stroke of Cylinder |
300mm |
High Pressure Pump Flowing |
About 89L/min |
Allowed Pressure |
≤25Mpa |
Power |
37Kw |
Pressure of Unit Plate Blank |
40Kgf/㎝2 |
Machine Weight |
About 32000Kg |
Control Method |
Automatic pump station |
Electrical Appliance |
Siemens |
Products Board Size |
2440x1220 |
Overall Size |
2650x3000x4340mm |
