Nominal Gross Pressure

12000KN

Direction of Feeding Plate

Vertical

Layer Counting

10

Distance Between Hot Platens

150mm

Numbers of  Hot Platens

11

Dimension of  Hot Platens

2700×1500×100

Numbers of Cylinder

6

Diameter of Cylinder

Φ320mm(Shanghai)

Stroke of Cylinder

1500mm

Pressurization

≤26 Mpa

Diameter of Power Tank

Φ1240x4000mm

Siemention

With

Empty Closing Time

About 11

The flux of Accumulator

3000 L/Min

Low Pressure Pump Flowing

171 ml/r

Allowed Pressure

≤3.5 Mpa

Power

15kw

High Pressure Pump Flowing

About 63 ml/r

Power

22kw

Middle Pressure Pump Flowing

160 ml/r

Allowed Pressure

15 Mpa

Power

45kw

Pressure of Unit Plate Blank

35 Kgf/㎝2

Dimensions of The Board

2580×1350mm

Control Method

Automatic pump station

Electrical Appliance

Suzhou Siemens

Pressure Gauge

Hangzhou

Hydraulic Valve

Shanghai\Youyan

Frame Pattern

 Composite Frame

Thickness of Upper And  Lower Crossbeams

800mm

Thickness of Steel Plate

40,30,20,12mm

Thickness of Plateform above

300mm

Thickness of Steel Plate

35,30,20mm

Steel Plate Of Upright Column

40,12mm

Thickness of Acctive Crossbeam

450mm

Thickness of Steel Plate

30,20mm

Overall Dimensions

2400×2700×5210mm

Total  Weight

About 85,000Kg
