SPECIFICATION:
Specification: 4P
Rated Temperature:
Unshielded twisted pairs:
Conductor: 26AWG or 24AWG Stranding or Solid Bare copper
Insulation: HD-PE
Unrip rope: optional
Jacket: PVC or LSNH
Impedance:100±15%Ω at 1~100MHz
Reference standard: YD/T1019-2001\ISO/IEC11801\ANSI/TIA/EIA-568B\UL 444
Print Legend: CM or CMR
Cable Assembly Specification:
Shape |
Conductor |
Insulation |
Core Number |
Jacket |
||||
AWG |
Specification (mm) |
Material |
Thickness (NOM.mm) |
Material |
Thickness (NOM.mm) |
OD (NOM.mm) |
||
Circular Cable |
26 |
1/0.404 |
HD-PE |
0.18 |
4P |
PVC or LSNH |
0.55 |
4.8 |
7/0.16 |
HD-PE |
0.18 |
4P |
PVC or LSNH |
0.55 |
5.0 |
||
24 |
1/0.511 |
HD-PE |
0.18 |
4P |
PVC or LSNH |
0.55 |
5.4 |
|
7/0.203 |
HD-PE |
0.18 |
4P |
PVC or LSNH |
0.55 |
5.5 |
||
Flat Cable (Non-sign) |
30 |
7/0.10 |
HD-PE |
0.13 |
4P |
PVC |
0.30 |
1.75*6.2 |
28 |
7/0.127 |
HD-PE |
0.13 |
4P |
PVC |
0.30 |
1.90*7.0 |
|
24 |
7/0.203 |
HD-PE |
0.18 |
4P |
PVC |
0.50 |
3.0*9.0 |
