Main application
The machine is mainly applied for pharmaceutical, chemical and foodstuff industries to grind wet powder into granules as well as to grind dry block into granules.
Working method
The material press sheet presses raw material with a certain angle to knives that are rolling due to mechanical driving. The big angle screw sheets on knives will push materials to sieve sides which will extrude them into granules.
MODEL | 250 | 300 |
Capacity(kg/h) | 100-200 | 120-300 |
granule diameterΦ (mm) | 0.5-3 | 0.5-3 |
power(kw) | 3 | 4 |
weight(kg) | 350 | 480 |
Overall size (L× W× H)(mm) | 700× 540× 1400 | 800× 650× 1400 |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() | |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
