Main application
The machine is suitable for material that need to concetrate, mix and dry at low temperature(foe example, biochemistry products) in chemistry, pharmaceutical and food stuff industries, especially suitable for drying of material apt to oxidize, volatilize and of strong heat sensitive and toxin and not permitted to destroy its crystal in drying.
Features
1. When oil is heated, automatic constant temperature control is applied. It can be used for drying biology products and mining material. Its temperature of operation canbe adjusted from 20-160° C and variation withinplusmn; 2° &c.
2. Compared with ordinary dryer, its heat efficiency will be raised over 2 times.
3. Indirect heating method prevents materials being polluted. Easy to use. It meets with the requirement of GMP.
| model | 100 | 350 | 500 | 800 | 1000 | 1500 | 2000 | 3000 | 4000 |
| inner tank volume(L) | 100 | 350 | 500 | 800 | 1000 | 1500 | 2000 | 3000 | 4000 |
| load volume(L) | ≤ 50 | ≤ 175 | ≤ 250 | ≤ 400 | ≤ 500 | ≤ 750 | ≤ 1000 | ≤ 1500 | ≤ 2000 |
| rotary speed(r/min) | 6 | 6 | 6 | 6 | 6 | 6 | 5 | 4 | 4 |
| motor power(kw) | 1.1 | 1.5 | 2.2 | 2.2 | 3 | 4 | 5.5 | 7.5 | 11 |
| floor area(L× W) | 2160× 800 | 2260× 800 | 2350× 800 | 2560× 1000 | 2860× 1300 | 3060× 1300 | 3260× 1400 | 3760× 1800 | 3960× 2000 |
| turnover height(mm) | 1750 | 2100 | 2250 | 2490 | 2800 | 2940 | 2990 | 3490 | 4100 |
| rate pressure in tank(Mpa) | -0.09~-0.096 | ||||||||
| rate pessure in jacket | ≤ 0.3 | ||||||||
| working temperature(º C) | inside tank≤ 85 | jacket≤ 140 | |||||||
| heating media | steam, hot water, | or heat transfer oil | |||||||
| weight(kg) | 825 | 1350 | 1650 | 1800 | 2100 | 2300 | 3000 | 4500 | 5400 |
