This machine suits to the drugs manufacture profession "GMP" the management, carries on to the drugs and the appliance antiseptic and is dry. This factory through accumulates for 30 years to make each kind of drying oven the experience and unifies the domestic and foreign experiences and the home "GMP" the request, the careful design, the manufacture, provides the reliable GM100 series product. Enjoys the high reputation in the medicine profession.
Principle of work
The material by the feeder even makeshift bed on the ground on the net belt, the net belt generally uses 12-60 item stainless steel silkscreens, drives by the transmission device in the dryer moves. The dryer is composed by certain units, each unit hot blast independent circulation, the partial exhaust by specially arrange the wet air blower to discharge, the waste gas by the regulating valve control, the steam upward or downward passed through the shop full material by under by on the net belt to complete thermal and the mass transfer advancement, carries off the material moisture. The net belt slow migration, the running rate may act according to the material temperature free adjustment, the dry after end product continuously falls receives in the material. About circulates the unit to need according to the user to be possible nimbly to provide, the unit quantity also may according to need to select.
Product use
The dehydrated vegetables, the diet pellet, the monosodium glutamate, the organic pigment, the synthetic rubber, the third thintextile fiber, the drugs, the raw material for medicine, the smallwoodware, the electronic non- component get older, the solidification and so on
Model | DW1.2-8 | DW1.2-10 | DW1.6-8 | DW1.6-10 | DW2-8 | DW2-10 |
Unit no. | 4 | 5 | 4 | 5 | 4 | 5 |
Belt weight | 1.2 | 1.2 | 1.6 | 1.6 | 2 | 2 |
Drying section length | 8 | 10 | 8 | 10 | 8 | 10 |
Subsidiary thickness | 10-80 | |||||
Working temperature | 60-150 | |||||
Steam temperature | 0.2-0.8 | |||||
Steam consumption | 120-300 | 150-375 | 150-375 | 170-740 | 180-500 | 225-600 |
Dry time | 0.2-1.2 | 0.25-1.5 | 0.2-1.2 | 0.25-1.5 | 0.2-1.2 | 0.25-1.5 |
Dry strength | 60-160 | 80-220 | 75-220 | 95-250 | 100-260 | 120-300 |
Blow power | 9.9 | 12.1 | 9.9 | 12.1 | 9.9 | 22.2 |
Total power | 11.4 | 13.6 | 11.4 | 13.6 | 19.7 | 23.7 |
