Specification:

Model: PUB-VH901-Z-WS

Image Sensor

Image Sensor

1/4" Color CMOS Sensor

Display Resolution

640 x 480 Pixels(300k Pixels)

Lens

3x Optical Zoom

Mini.Illumination

0.5Lux, F2.0

Lens

Lens Type

Glass Lens

Viewing Angle

30.7°~ 69°

Audio

Input

1 channel audio input

Output

1 channel audio output

Audio Compression

G.711

Video

Image Compression

H.264, MJPEG

Image Frame Rate

30fps(VGA),30fps(QVGA)

Resolution

640 x 480(VGA), 320 x 240(QVGA)

Flip Mirror Images

Vertical / Horizontal

Light Frequency

50Hz, 60Hz, Outdoor

Video Parameters

Brightness, Saturation , Contrast ,Hue

Communication

Ethernet Interface

Build in 10/100Mbps,Auto MDI/MDIX , RJ-45

Supported Protocol

TCP/IP HTTP DNS DHCP PPPoE SMTP FTP SSL TFTP NTP ARP/RARP NFS RTSP RTP RTCP.

Compress rate level

128Kbps~4Mbps

Wireless Standard

IEEE 802.11b/g

Data Rate

802.11b: 11Mbps (Max.), 802.11g: 54Mbps (Max.),
802.11n: 150Mbps (Max.)

Wireless Security

WEP & WPA WPA2 Encryption

Physical

Pan/Tilt Angle

Horizontal:355° & Vertical: 90°

Alarm Input

1 Channel on/off Input

Alarm Output

1 Channel relay Output

Dimension

Gross Weight

Color Box

Power

Power Supply

DC 12V/2.0A (EU,US,AU adapter or other types optional)

Power Consumption

10 Watts (Max.)

Environment

Operate Temper.

0°C ~ 55°C? (14°F ~ 131°F)

Operating?Humidity

20% ~ 85% non-condensing

Storage Temper.

-10°C ~ 60°C

Storage Humidity

0% ~ 90% non-condensing

PC System Requirements

CPU

2.0GHZ or above (suggested 3.0GHz)

Memory Size

256MB or above (suggested 1.0GHz)

Display Card

64M or above

Supported OS

Microsoft Windows 2000/XP/Vista/7

Browser

IE6.0/7.0/8.0/Firefox/Safari/Google chrome or other standard browsers

Certification

CE, FCC, RoHS

Warranty

Limited 1-year warranty
