Specification:

Model: PUB-VH501-MPC-WS

Image  Sensor

 Image Sensor

1/4" Micron CMOS Progressive Scan CMOS

 Display Resolution

Primary Stream: 1280*800 (30fps), 640*400 (30fps)

 Lens

f: 3.5-8mm

 Mini. Illumination

0.5Lux

Lens

 Lens Type

Glass Lens

 Viewing Angle

81 Degree-35 Degree

Audio

 Input

Built-in Microphone/1 channel audio output

 Output

1 channel audio output

 Audio Compression

ADPCM

Video

 Image Compression

H.264, MJPEG

Resolution/Frame Rate

Primary Stream:1280*800 (30fps), 640*400 (30fps)

 Flip Mirror Images

Vertical / Horizontal

 Light Frequency

50Hz, 60Hz

 Video Parameters

Brightness, Saturation , Contrast ,Hue

Communication

 Ethernet Interface

Build in 10/100Mbps,Auto MDI/MDIX , RJ-45

 Supported Protocol

TCP/IP HTTP DNS DHCP PPPoE SMTP FTP SSL TFTP NTP ARP/RARP NFS RTSP RTP RTCP.

Compress rate level

128Kbps~16Mbps

Wireless Standard

IEEE 802.11b/g

Data Rate

802.11b: 11Mbps (Max.), 802.11g: 54Mbps (Max.),

Wireless Security

WEP & WPA WPA2 Encryption

Physical

 Alarm Input

2 Channel on/off Input

 Alarm Output

1 Channel relay Output

Power

 Power Supply

DC 12V/2.0A (EU,US,AU adapter or other types optional)

 Power Consumption

6~10W(refer to specific product model)

Environment

 Operate Temper.

0° ~ 55°C  (14°F ~ 131°F)

 Operating  Humidity

20% ~ 85% non-condensing

 Storage Temper.

-10°C ~ 60° (14°F ~ 140°F)

 Storage Humidity

0% ~ 90% non-condensing

PC System Requirements

 CPU

2.0GHZ or above (suggested 3.0GHz)

 Memory Size

256MB or above (suggested 1.0GHz)

 Display Card

64M or above

 Supported OS

Microsoft Windows 2000/XP/Vista/7

 Browser

IE6.0/7.0/8.0/Firefox/Safari/Google chrome or other standard browsers

Certification

 CE, FCC, RoHS
