| Euro Ⅲ | Euro Ⅱ | ||||
| Model | Unit | SC5DT160Q3 | SC5DT180Q3 | 4CT160 | 4CT180 |
| Fuel | Natural gas CNG | ||||
| Type | 6～Cylinder 4 Stroke, Water cooled | ||||
| Aspiration | Cold turbocharger /TCI | ||||
| Bore×Stroke | mm×mm | 114×114 | |||
| Total Displacement | L | 9 | |||
| Compression Ratio | 11:1 | ||||
| Rated Power/ Rated Speed | Kw/r/min | 206/2200 | |||
| BMEP@Rated Condition | kPa | 1359 | |||
| Maximum Thermo Efficiency | % | 37 | |||
| Oil Consumption Rate | g/kW.h | ≦0.3 | |||
| Maximum Torque/Speed | N.m/r/min | 1110/1300.1400 | |||
| Noise | dB(A) | ≦96 | |||
| Overhaul Interval | km | ≧400000 | |||
| Overall Dimension | mm | 1345(Length)×715(Width)×1075(Height) | |||
| Weight | kg | 640 | |||
