Model Number: Y-II -530K

Minimum Order Quantity : 50 Piece/Pieces

Supply Ability: 1000 Piece/Pieces per Month

1) Size & Weight :

- ExternalSize (H x W x D): 532 x 374 x 426(mm); 20.9 x14.7 x16.8(inch)

- Internal Size ( H x W x D): 420 x 304x 320(mm); 16.5 x12.0 x12.6 (inch).

- Interior Cubic feet : 1.47ft³

- Net Weight: 62±3kg /137±6 lb

2) Interior and shelving

- Two adjustable shelves

- Chrome plated bolt guide

3) Material

- Double wall solid steel plate . 2mm for inner case , 4mm for outer case,  8mm for door

4) Lock & handle

- High security VdS Class 1 approved double bitted key lock (2 keys supplied,STUV).

5) Security feature

- Chrome plated 25mm dim solid steel boltwork ,

- Inner hinge to prevent hinge cutout

- Extra strong dead bar to prevent prying attack

- Direction and q'ty of bolt ( Horizental - top - bottom - deadbar) : 3-0-0-2

- Anti drilling manganized hardplate protecting lock.  .

- Additional manganized hardplate protecting each bolt deterring from side attack.

- Safes designed to meet latest European burglary test standard EN14450 -S2.

- 30 minutes fire resistance at 750 degrees (Factory test)

6) Color and Finish

- Durable powder coat Dark Grey RAL7001

- Color option : other color available for order q’ty over than 100 pcs.

7) Accessory

- Total 4 anchor bolt holes(12mm)on the bottom and back. .

4 anchoring bolt (10mm) and plastic bolt hole covers included. .

8) Standard option :

- Customer Logo : Please contact us for MOQ and additional cost.

- Optional Motion sensitive interior lighting with magnet (attached onto the ceiling).

- Please contact us if you have other needs.

9) All model in the same serise.

** Y-I series are single wall none fire proof. Y-II are double wall fire proof safes.

** Sales restricted area :Europe
