9.5HP Gasoline Engine

Brand Name TICO POWER or OEM

1) Place of Origin Fujian, China (Mainland)

2) Price: FOB40-70USD/Set

3) Port: Fuzhou

4) Delivery Time: 20 Days

5) Payment Terms: L/C,T/T,by negotiation

6) Supply Ability: 6000 Set/Sets per Month

7) Minimum Order Quantity: 50 Set/SetsTrial Order

8) Color Customer colors available
====================================================

Features

• Certification CE, EPA
•  12Months Quality Warrarry
• Usage used in generator set, power tiller, water pump sets, Ship motor, ect.

====================================================

Specification

Model :  TG188F(E)

Bore*Stroke (mm*mm) :  88*64

Displacement (ml) :  389

Compression Ratio :  8.5:1

Engine Speed (rpm) : 3000/3600

Continuous Output (HP) :  9.5

Max Power Output(HP) : 12

Fuel Consumption (g/kw.h) :  374

Ignition Mode :  Transistor Ignition (TCI)

Start Model :  Recoil or Electric

Fuel Model :  Automotive Unleaded Gasoline (90#, 93#)

Lube Model :  SAE 10w 30(Above CC Grade)

Oil Capacity (L) : 1.1

Fuel Tank Capacity :  6.5

Net Weight (KGS) : 31(R)/33.5(E)

Gross Weight (KGS) :  33.5(R)/36(E)

Dimensions (L*W*H) mm :  520X440X480

Packing Size (L*W*H) mm :  535X455X500
