6.5KVA 3 Phases Gasoline Generator Set

Brand Name TICO POWER  or OEM

1) Place of Origin Fujian, China (Mainland)

2) Price: FOB290-330USD/Set

3) Port: Fuzhou

4) Delivery Time: 20 Days

5) Payment Terms: L/C,T/T,by negotiation

6) Supply Ability: 7000 Set/Sets per Month

7) Minimum Order Quantity: 10 Set/SetsTrial Order

8) Color Customer colors available
9) Contract Manufacturing: OEM Service Offered

10) Certification CE, EPA, ISO

===================================

Features

1) 12Months Quality Warrarry
2) Low fuel consumption
3) High quality promise

4) Color Customer colors available
5) Copper wire

===================================

Specification

Model: TGG8500F(E)-3

Generator

AC Frequency: 60Hz

AC Output (V): 380,230/400,277/480

Cont.AC Output: 6.5KVA

Max AC Output: 7.5KVA

DC Output (V/A): 12/8.3

Insulation: F

Phase Number: Three Phases

Power Factor: 0.8

Engine

Engine Model: TG190F(E)

Engine Type: Air-Cooled, 4-Stroke, Gasoline Engine, Single Cylinder,OHV

Displacedment: 420CC

Engine Speed: 3600RPM

Starting System: Recoil or Electric

Max Power Output: 15HP

Fuel Model: Automotive Unleaded Gasoline(90#,93#)

Fuel Tank Capacity: 25L

Continuous Operating: 7hr

Operating Noise Level: 76DB

Dry Weight: 95KGS

Gross Weight: 106KGS

Dimensions (L*W*H): 685X560X545mm

Packing Size (L*W*H): 710X580X575mm
