BST-60E
Basic voltage DC accuracy: ±0.5%Function: Data hold, Frequency/Duty ratio and on/off warning, with back light display.
Testing: voltage DC, voltage AC, Resistance, Capacitance, and New increasing temperature testing for diode, Valid value of Alternating current testing.
Body color, body-metal gray: shake-proof cap: yellow or red
Body weight:BST-60 E/320g
Standard accessories: meter pen ,point temperature probe, battery, instruction, Eligible Certificate
Standard inner packing: color box
Standard quantity of packing:30 units
BEST-60E 3¾ digital multi-meter technical indicators
|
Basic Function |
Range |
Basic precision |
|
Voltage DC |
400Mv/4V/40V/400V/1000V |
±(0.8%+1) |
|
Voltage AC |
4V/40V/400V/750V |
±(1%+5) |
|
Direct current |
400Ua/4000Ua/40mA/400Ma/4A/10A |
±(1%+2) |
|
Alternating current |
400Ua/4000Ua/40mA/400Ma/4A/10A |
±(1.5%+5) |
|
Resistance |
400/4k/40k/400k/4M/40M |
±(1 %+2) |
|
Capacitance |
40nf/400nF/4uF/40Uf/100uF |
±(3 %+5) |
|
Temperature |
-40℃~1000℃ |
±(1 %+3) |
|
Frequency |
10Hz~10MHz |
±(0.1 %+3) |
|
Duty Ratio |
0.1%~99.9% |
√ |
|
Special function |
||
|
10A fuse |
|
√ |
|
Relative measurement |
|
√ |
|
Diode testing |
|
√ |
|
on/off warning |
|
√ |
|
Full symbol display |
|
√ |
|
Sleeping function |
|
√ |
|
Hint of low battery |
|
√ |
|
Input impendance of voltage measurement |
10M |
√ |
|
Data hold |
|
√ |
|
Automatic measurement |
|
√ |
|
Selection of automatic and manual drive |
|
√ |
|
Apheliotropism |
|
√ |
|
Valid value |
AC |
√ |
|
Shake-proof protection |
|
√ |
|
Power supply |
9V battery(6F22) |
√ |
|
Maximum display |
3999 |
√ |
|
Display size |
66mm*39mm |
√ |
