Technical Information:
Type | Power 600W |
Rotor Diameter | 1.2m ( ~4 ft.) |
Rated Wind Speed | 7-8m/s ( ~16 mph) |
Rated Power | 600W |
Max Power | 750W |
Output voltage | 220/110 |
Cut-in wind speed | 2m/s ( ~6 mph) |
Work wind speed | 2-24m/s ( ~6 - 54 mph) |
Rotation wind speed | 150r/min |
Turbine weight (tower excluded) | 63kg ( ~139 lbs.) |
Blade Material | FRP (Fiberglass reinforced plastic) |
Number of blades | 8 |
Swept Area | 4m ( ~13 ft.) |
Tower height | 10m ( ~33 ft.) |
Tower type | Steel (Q235B), with iron cables for extra support (if needed) |
Battery type | 12v100AH 2pcs |
Output control system | Controller, inverter |
Service life | 20-25years |
