Caterpillar Haulage Device

Original Image

Products Visitors:262

Product Name:Caterpillar Haulage Device
MODEL:SJ
PACKAGE:wood case

Products description: Caterpillar Haulage Device

Multi-caterpillar Haulage Device

● It is equipped with two, three, four, six or eight-caterpillar, so applicable pipe diameter is 20-1200mm. driving of all caterpillars adopts differential type couplings to ensure the equal load distribution between all caterpillars, avoid the stress deformation of driving chain and prevent gear case from overloading.
● V-style rubber block directly connects with the chain
● Under the conditions that the frictional coefficient between pad and pipe is much lower, the air cylinder with large dimension guarantees the high tractate power.
● All caterpillars adopt parallel guiding in end, lower caterpillar needs to be adjusted to needed traction position. Up caterpillar is driven by air cylinder to automatically adapt to the variation of pipe diameters and keep excellent contact pressure with outer wall of pipe.

Model	R125/4	R250/4	R450/4	R630/6	R1200/8
Diameter(mm)	20-125	75-250	200-450	315-630	450-1200
Touchable Length(mm)	1200	1400	1600	1600/2000	2000/2500
Max traction(N)	7500	10000	20000	30000	3500
Speed range(m/min)	0.3-15.0	0.2-10.0	0.1-5.0	0.05-2.5	0.05-1.5

Product Images: Caterpillar Haulage Device
