Item name

Laboratory Horizontal Flow Hood, Fume Hood, Metal Fume Hood

Specification

1200*1500*1800*800*2350mm (4'/5'/6'x2'8"x7'8")

Design Basis

China industrial standard<Fume Hood>

Shell

1.2mm thickness high quality cold-rolled steel with 0.5mm thickness of static epoxy resin power coated

Lining

Chemical & Heat Resistant, Fire Retardant, Smooth Finish, Easily Cleanable Panels Made out of durable Phenolic integral work walls (5 mm thick).

Sash Opening

Minimum: 50mm; Maximum: 700mm

Average face velocity

0.5m/s

Front Top Panel

Easily openable hinged Top Panel for easy access to Flow Control Valve and Electrical Lighting fixtures for maintenance.

Work top

Chemical resistant, splash & spillage proof dished 20mm Ceramic Work top with built-in rounded edges rim on all four sides, or Trespa, Chemsurf, Epoxy Resin

Windows

5mm toughened

Window handle

1.5mm carbon steel

Illumination

30W fluorescent lamp group, at least 300LUX

Sink

Imported PP pool

Faucet

Use brass body laboratory faucet with international ceramic valve core featured slowly down water pressure. The surface is coated with epoxy resin powder

Exhaust duct

Glass steel tube or PVC tube, corrosion resistance

Base

1.2mm thickness cold rolled steel sheet with 0.5mm thickness of epoxy resin powder finish

Socket

15amp switch with three sockets

Technical data

Noise: ≤60dB(international): wind speed: three-section exhaust

Function

Intelligent auto-delay protected device, to prolong life by evacuate etchant gas

Certificate

ISO 9001:2008

MOQ

5 Pieces

Payment

L/C, T/T

Brand
