Mica  Heater

1.It is fully utilize the mica's High temperature resistant and electrical insulation performance,with mica piece as a base and complementary with other plank, heat wire winding its or clamp pressure among them, powered and give off heat, obtaining good thermal effect

2. Voltage: 100--240v
     Power : 100-3000w

3.  Features of YAT mica heating sheet:
1) Top qulity material used:Mica,temperature control, terminals, lead wire,casing are all UL and SGS certification.heating wire,  iron chromium wire and nickel chromium wire;mica sheet is muscovite and phlogopite,thermostat we buy in our country and Korea and those which is produced by Texas Instrument.
2) With reasonable heating frame structure,coiling distribution uniform, creepage distance is enough, as a resullt the ventilated function is in superior performance.
3) Craft is perfectly good,stents firm meanwhile fuses's  tension is excellent
4)  Products are heating fast, with feaatures of quick heat dissipation,high efficiency and long working life
5)  Products are stictly inspected before leaving the factory

Product certification:

Specification
1. Insulation Material: Muscovite / Phlogopite mica plate

2.Heating Wire: Ni80Cr20, OCr25Al5A

3.Voltage Range:100 – 240 V

4.Power Rating: depending upon application.

5.Operating Temperature: depending upon ratings, motor, construction of heater etc.

6.Dimension: customers’ requirement.

7.protection: customers’ requirement.

Note:

Various specification can be made according to customers’ drawings.


Application:

Mica heater are widely applied  Home appliances,Hair dryers, Wool dryers, Hand dryers,  Fan heater, Convection heater  Toaster ,Office equipment, Industrial machinery, and other electric heating products.

Package:

Protective package: pallet or wooden case.
