Super light frame, the big down tube, the wide chain stay and the oversized head tube make this frame an amazing comfort and stiffness.

GEOMETRY


* *Not all sizes available in all markets
Size	480mm	500mm	520mm	540mm	560mm	580mm
Seat Tube (BB Center to Top)	480mm	500mm	520mm	540mm	560mm	580mm
Top Tube (effective)	510mm	520mm	540mm	555mm	570mm	590mm
Chain Stay (actual)	406mm	406mm	406mm	406mm	408mm	410mm
Seat Tube Angle	74.5°	74°	73.5°	73.5°	73°	72.5°
Bottom Bracket Drop	70mm	70mm	70mm	70mm	70mm	70mm
Head Tube Length	115mm	125mm	140mm	155mm	170mm	185mm
Head Tube Angle	71.5°	71.8°	72.5°	73°	73°	73.5°
Seat-Post ID	31.6mm	31.6mm	31.6mm	31.6mm	31.6mm	31.6mm
Seat-Clamp ID	34.9mm	34.9mm	34.9mm	34.9mm	34.9mm	34.9mm
Fork Length	368mm	368mm	368mm	368mm	368mm	368mm
Fork Rake	45mm	45mm	45mm	45mm	45mm	45mm
Wheelbase	963mm	966mm	975mm	986mm	997mm	1009mm
Front-Center	568mm	571mm	580mm	590mm	600mm	609mm
Handle-Bar Width	420mm	420mm	420mm	420mm	420mm	420mm
Crank Length	170mm	170mm	170mm	170mm	170mm	170mm
Seat-Post Length	350mm	350mm	350mm	350mm	350mm	350mm
