By optimizing the internal structure to create super light frame, with the strengthening design of high rigid B.B, force more direct, accelerate the rapid, on stepping reactions are extremely sensitive to the rider, appeal each pedal hundred-percent conversion for speed.And match with the super light carbon fork, which make you have a good riding on the city.
| TECHNICAL SPECIFICATIONS | |
| MODEL | MASERATI |
| COLOR | 3K GLOSSY, RED GRAY |
| FRAME | WIEL B083 |
| SIZE | 26"MTB, 17"/19" ARE IN STOCK |
| FORK | FK R015 |
| BRAKE | SHIMANO 446 |
| CHAIN | SHIMANO 430 |
| CRANKSET | SHIMANO 430 |
| SHIFT LEVERS | SHIMANO 430 |
| FRONT DERAILLEUR | SHIMANO 430 |
| REAR DERAILLEUR | SHIMANO 430 |
| STEM | ITM 31.8*90mm |
| HANDLEBARS | ITM 31.8*580mm |
| SEATPOST | ITM 31.6*350mm |
| SADDLE | WIEL,BLACK |
| CASSETTE | SHIMANO 430 |
| WHEELS | RT |
| TIRE | CST 26*1.95 |
| INNER TUBES | CST 26*1.90 |
| WEIGHT | 9.8kg |
| GEOMETRY | ||||
| * *Not all sizes available in all markets | ||||
| Size | 15“ | 17” | 19“ | 21” |
| Seat Tube (BB Center to Top) | 381mm | 430mm | 483mm | 534mm |
| Top Tube (effective) | 555mm | 580mm | 610mm | 630mm |
| Chain Stay (actual) | 425mm | 425mm | 425mm | 425mm |
| Seat Tube Angle | 73.5° | 73.5° | 73° | 73° |
| Bottom Bracket Drop | 30mm | 30mm | 30mm | 30mm |
| Head Tube Length | 115mm | 120mm | 130mm | 140mm |
| Head Tube Angle | 70.5° | 71° | 71° | 71.5° |
| Seat-Post ID | 31.6mm | 31.6mm | 31.6mm | 31.6mm |
| Seat-Clamp ID | 34.9mm | 34.9mm | 34.9mm | 34.9mm |
| Fork Length | 456mm | 456mm | 456mm | 456mm |
| Fork Rake | 42mm | 42mm | 42mm | 42mm |
| Wheelbase | 1048mm | 1068mm | 1093mm | 1108mm |
| Front-Center | 625mm | 645mm | 670mm | 685mm |
| Handle-Bar Width | 580mm | 580mm | 580mm | 580mm |
| Crank Length | 170mm | 170mm | 170mm | 170mm |
| Seat-Post Length | 350mm | 350mm | 350mm | 350mm |
