Model

HMLW-8

Max. Digging Depth (mm)

2640

Max. Digging Radius (mm)

3930

Max. Digging Height (mm)

3510

Loading Height (mm)

2000

Swing Arc (deg.)

160

Bucket Rotation (deg.)

160

Connect Height (mm)

460

Connect Width (mm)

530

Valve Standard Pressure

16Mpa.

Load Capacity (m3)

0.054

Structural Weight (kg)

680

Shipping Dimensions (mm)

2200*800*1600

Bucket Width (mm)

500

Power Required (hp)

50-80

Max. Digging Length (mm)

1610
