BW-D series (Metal case)thermal protector

Original Image

Products Visitors:849

Product Name:BW-D series (Metal case)thermal protector
Model:BW-D
Size:18*5.6*3.6mm
Package:32*26*22

Products description: BW-D series (Metal case)thermal protector

Application Field:

Be used in
1. Battery packs
2.Pumps
3. Cooling fans
4. Heating appliance
5. Lighting ballast

The Product Sells Point:

1. Case not charged,without insulating sleeve(solve installation problem of sleeve off and broken)
2. Temperature sensitive
3. Better pressure resistance

Key Specifications/Special Features:

1.Dimension case: with leading wire 60mm normally
Metal:18x5.6x3.6mm

2..Rated voltage: AC250V/24V (50/60Hz)
3.Rated current: 6A
4.Rated open temperature range: 40~145C, in steps of 5C
5.Tolerance: (+/-)5C
6.Resetting temperature : lower than rated open temperature 30C(+/-)15C
7.Switching cycles in: 10000 cycles
8.Contact arrangement:Normally closed&Normally open
9.Standard contact resistance: lower than 50mohm

Pack Information:

To be informed

Third Party Certificates:

UL ROHS

Product Sample Availability Policy:

Free below 10 pcs samples but transport charged

Order Lead Times:

About two weeks

Minimum Order Quantity:

Product Images: BW-D series (Metal case)thermal protector
