Shenzhen Ruby Technology Development Co.,ltd

Hardware Platform MTK 6575(up to 1.2 G Hz)

Operation System Google Android 4.0  1GHz Cortex-A9

Telecommunication Frequency Band System 3G：WCDMA/EDGE/

2.5G：GSM/GPRS

Camera Cam. Location façade

pixels The front with 0.3Mega，THE REAR WITH 2Mega

type CMOS

Flash Light SMT

Hareware Configuration Display screen Dimension:7”

Resolution:SHD1024*600

Type:TFT

TP Multi-point Capacitive Touch Panel

WiFi+Bluetooth Support（USB WiFi+RDA bluetooth module（voice call））

Bluetooth Support BT 3.0HS+BT 4.0 LE

FM Support

Vibration Motor Support

Audio Format MP3、AAC、AAC+、EAAC+、AMR、WB-AMR、MIDI、Ogg Vorbis、PCM decode

Video Format ● Support SHD（720P）VIDEO decoding, H.264, H.263, VC-1, MPEG-1/2/4,

● Support H.264 Coding，720P@100fps.

● Support universal music-play format,such as MP3，WMA，AAC etc.

RAM Nand flash:4G(support up to 8G/16G)

DDR3:128×4（512MB）/support up to 256*4(1GHZ)

Antenna Built-in

GPS Support(embedded)

G-SENSOR Support（7660，8452）

Battery Voltage:3.7V

Capacity: 3200mAh

ATV Support

I/O Interface Earphone Interface Standard 3.5mm port

Speaker 2030mm*1

Extended RAM Type:Plug & Play

Capacity:32G

SIM Card Support

MIC Support

Power Jack Support

Function Key 4pcs x Façade capacitive touch keys（HOME，ESCAPE, MUTE, search）

3pcs x flank buttons（power on/off & volume +/-）

Key Backlight support

Language-Version Chinese/English

others to be defined

Hand-Writing Input Support

Key-Board Input soft key-board

International Key-Board Asia：China

North America：America（English）

others to be defined

Entertainment Audio-Plany

Video-Play

E-Album

Accessaries 1pc charger/1pc data cable/1pc earphone cable/user manual/gift-box

Measurement 195*124*11mm

Features 3G Module bulit-in(compatible with 2G), support Bluetooth Voice-Call/GPS/BT/FM/WIFI,ATV
