Shenzhen Ruby Technology Development Co.,Ltd
Hardware Platform MTK 6577 1.0GHz Cortex-A9
Operation System Google Android 4.0
Telecommunication Frequency Band System 3G:WCDMA/EDGE/
2.5G:GSM/GPRS
Camera Cam. Location façade
pixels The front with 0.3Mega,THE REAR WITH 2Mega
type CMOS
Flash Light SMT
Hareware Configuration Display screen Dimension:7”
Resolution:SHD1024*600
Type:TFT
TP Multi-point Capacitive Touch Panel
WiFi+Bluetooth Support(USB WiFi+RDA bluetooth module(voice call))
Bluetooth Support BT 3.0HS+BT 4.0 LE
FM Support
Vibration Motor Support
Audio Format MP3、AAC、AAC+、EAAC+、AMR、WB-AMR、MIDI、Ogg Vorbis、PCM decode
Video Format ● Support SHD(720P)VIDEO decoding, H.264, H.263, VC-1, MPEG-1/2/4,
● Support H.264 Coding,720P@100fps.
● Support universal music-play format,such as MP3,WMA,AAC etc.
RAM Nand flash:4G(support up to 8G/16G)
DDR3:128×4(512MB)/support up to 256*4(1GHZ)
GPS Support(embedded)
G-SENSOR Support(7660,8452)
Battery Voltage:3.7V
Capacity: 3500mAh
ATV Support
I/O Interface Earphone Interface Standard 3.5mm port
Speaker 2030mm*1
Extended RAM Type:Plug & Play
Capacity:32G
SIM Card Support
MIC Support
Power Jack Support
Function Key 4pcs x Façade capacitive touch keys(HOME,ESCAPE, MUTE, search)
3pcs x flank buttons(power on/off & volume +/-)
Key Backlight support
Language-Version Chinese/English
others to be defined
Hand-Writing Input Support
Key-Board Input soft key-board
International Key-Board Asia:China
North America:America(English)
others to be defined
Entertainment Audio-Plany
Video-Play
E-Album
Accessaries 1pc charger/1pc data cable/1pc earphone cable/user manual/gift-box
Measurement 196.6 * 122.6* 11.6 mm
Features 3G Module bulit-in, support Bluetooth Voice-Call/GPS/BT/FM/WIFI,ATV
