Specifications | |||
| CPU | Type | Z670(1.5G 512K) | ||
| Install Method | BGA | |||
| Power Consumption | 3W | |||
| Level 2 Cache | Depend on CPU | |||
| Major Chipsets | Chipsets | SM35 | ||
| System Memory | Capacity | SMT on board | ||
| Type | Support up to 800 | |||
| Max. Memory | 2GB (Maximum) | |||
| Display | LCD (16:9) | 10.1" 16:9 TFT LCD | ||
| Resolution 1024*600 | ||||
| Storage | HDD | SSD HDD, SATA interface, 8G/16G/32G | ||
| Graphic | Graphic Controller | Integrated | ||
| I/O Devices | Point Device | Touch Panel(Multi-finger support) | ||
| Web Cam | 1.3M Pixel | |||
| Card Reader | MicroSD card (TF card) | |||
| Sensor | G-Sensor/Gyro Sensor/Compass | |||
| Communications | Networking devices | Integrated 10/100/1000 bps Ethernet | ||
| Wireless networking devices | 802.11 b/g/n & Bluetooth(Bluetooth Optional) | |||
| 3G module(Optional) | ||||
| I/O Port | Standard | 2× USB 2.0 connectors | ||
| 1× Headphone-out/MIC-in jack | ||||
| 1× DC-In jack | ||||
| 1× TF card reader slot | ||||
| 1× SIM card slot (Option with 3G module) | ||||
| 1×HDMI | ||||
| 1×Push Button Switch | ||||
| Audio | Features | High Definition AudioStereo | ||
| support two (1.5 W per each channel) speakers | ||||
| Internal Microphone | ||||
| Keyboard | Keyboard type | USB Keyboard (option) | ||
| POWER | AC Adapter | 90~ 265V AC, 50~60Hz Output: 19V, 2.2A, 40W | ||
| Battery Pack | 2 cells ,Polymer Battery ,7.4V ,2S1P, 6200mHA | |||
| Dimensions & Weight | 173 x 267 x 17.5 | |||
| TBD | ||||
| Cosmetic | Case | A: Glass | ||
| B: Plating | ||||
| Brand Name | Logo | TBD | ||
| MS Windows OS | Windows 7 Starter/Premium, | |||
| OS Certification | MS Windows Logo | System Logo:Windows7 | ||
