Features:
1. Newly changeable dot technology
Big, middle and small dot technology could improve the graduation of picture. More vivid and smooth.
2. Advantage feather technology
The feather technology can avoid banding or wave line during printing.
3. Safety sub-tank system with ink filter
Use the most reliable sub-tank system, keep a stable liquid level, support better fluency of printing. And ink filter could prevent printhead from clog.
4. Stable control system
More than 24 hours test in factory, guarantee the best quality.
5. Warranty: 1 year;
Technical Parameter
|
Model |
ES-P1801 ES-P1802 |
|
|
Max. Printing width |
1800mm |
|
|
Printing Technology |
Advanced Micro Piezo printhead; Dual 4 colors; 8-channel, drop-on-demand, ink jet print head |
|
|
Printhead type Printhead quantity |
Epson DX5 / DX7 optional; One head / Two head optional; |
|
|
Ink type |
Disperse dye ink (dye sublimation ink), Active ink, Eco solvent ink, Water-based ink etc. |
|
|
Ink color |
4-color(K, C, M, Y) |
|
|
Ink supply system |
Automatic ink supplying by electric pump |
|
|
Printing Media |
transfer paper, cotton, polyester, other synthetic fabrics and textile materials, banner, vinyl etc. |
|
|
Maximum Resolution |
720 x 2880 dpi |
|
|
Printing Speed |
2PASS |
25 m2/h 50 m2/h |
|
4PASS |
14.5 m2/h 29 m2/h |
|
|
6PASS |
12 m2/h 24 m2/h |
|
|
8PASS |
8.1 m2/h 16.4 m2/h |
|
|
Print Head Cleaning system |
Automatic cleaning device, Automatic scraping ink device |
|
|
Roll-up System |
Optional |
|
|
Data Interface |
USB2.0 high speed interface transfer system |
|
|
Working Environment |
Temperature:15-30 ℃ Humidity: 50%-80% |
|
|
Power supply |
50 – 60 Hz AC220V（±10%）/AC110V(±10%) |
|
|
Operating Systems |
Windows XP, Windows XP Professional x64 Edition Windows 7 Professional x32 Edition |
|
|
Machine Dimension |
2775mm(L) x 630mm(W) x 1240mm(H) |
|
|
Machine Weight |
205Kg |
|
