Rubber Powder Line is mainly used to produce the rubber powder with 5-30mesh from steel wire tire, inner tube, flap, etc

the production process is as follows:

waste tire---cut off bead by bead cutter and the steel wire is separated from the bead by bead separator---- tire body is cut into strip with width 25mm by strip cutter----width-25mm strip is cut into 25x25mm rubber block by block cutter---the 25x25mm blocks is transmitted to the cracker to break to 5-30 mesh rubber powder,  magnetic seperater clear the steel wire from the power.

the production line is mainly including the machines as follows:

1. main machine: XKP-560, XKP-450 cracker

2. auxiliary machine:

bead cutter,

strip cutter,

block cutter,

steel wire separator

conveyor belt,

oscillating screen,

small conveyor belt,

small oscillating screen,

double layer magnetic separator.

3. you can add a fibre separator to wipe off the fibre, and add a grinder to get 60-100 mesh rubber powder at the end of production line.

if you want other different producing procedure rubber powder producing line, please contact .

we can offer various of rubber powder producing line for your choice.
