·35% wind energy utilization

·Low start up wind speed

·Wind & solar hybrid controller

·Easy installation

·Minimal vibration & low noise

·Damp-proof & sand-proof

·Anti-rust & Anticorrosion

·Long lifespan over 15years

Model

JFVC-300W

JFVC-500W

JFVC-1KW

JFVC-2KW

JFVC-3KW

JFVC-5KW

Diameter of wind wheel (m)

1.6

1.8

2.2

2.4

2.7

2.7

Blades dimension (mm)

1120X360

1650X410

1830X410

2160X450

2600X500

3000X500

Rated rotate speed (r/min)

80

80

50

50

50

50

Rated wind speed (m/s)

8

8

10

10

11

11

Start up wind speed (m/s)

2

2

2.5

2.5

2.5

2.5

Working wind speed (m/s)

3-25

3-25

3-25

3-25

3-30

3-30

Survival wind speed (m/s)

40

Blades quantity

5

Material of blades

Fiberglass reinforced plastics

Generator type

3phase AC PMG

Generator protection

IP54

Generator housing

cast iron

cast iron

cast iron / Aluminium

cast iron / Aluminium

cast iron / Aluminium

cast iron / Aluminium

Rated power (W)

300

500

1000

2000

3000

5000

Max power (W)

350

550

1200

2500

3500

5500

Rated voltage (DC/V)

12/24

24/48

24/48

48/96/120

220

220

Tower height (m)

6

6

8

8

8

9

Guy cable tower (mm)

89*6

96*6

114*6

114*6

203*6

203*6

Battery reference

12V100ah, 2pcs

12V100ah, 2pcs

12V100ah, 4pcs

12V150ah,4pcs/ 12V100ah,8pcs

12V100ah, 18pcs

12V150ah, 18pcs
