Type

HY-400WL

Rated Output

400W

Peak Output

500W

Rated Voltage(V)

DC12/24

Start-up Speed

2m/s

Cut-in Speed

2.5m/s

Rotor Diameter(m)

1.55

Swept Area (m2)

1.89

Rated Charging Current (A)

33.3/16.7

KWH/month (monthly avg. V=5.5m/s)

82

Net Weight

22KG

Quantity Of Blades

5

Rated Rotor Speed (RPM)

750

Rated Wind speed(m/s)

12m/s

System Average Cp.

≥0.36

Working Temp. range °C

from -40°C to 60°C

Survival Max. Wind

50m/s or 110mph

Over-speed Control

Electromagnetic & blade aerodynamic braking

Blade Material

Reinforced nylon glass-fiber

Generator Type

Brushless 3-phase with permanent Neodymium Magnet

Generator Material

Aluminum alloy body & precision stainless steel rotor

Noise Level

＜20dB (5m behind turbine @ 5m/s gusting)

Tower Connection

Flange connection

Lifespan(years)

15

Warranty (years)

3

Years On Market

7
