Application

Abdomen organs, obstetrics and gynecology, heart, superficial examination.

Imaging technology

Full digital beam former, continuous dynamic aggregation and continuously variable aperture , the A / D sampling 32 channels

Scanning mode

Eletronic convex and linear with wide and multi-frequency

Dynamic range

64-96dB adjustable

Display Mode

B, B/B, B+M, M, 4B

Magnification Zoom

×0.8,×1.0, ×1.2, ×1.5, ×1.8, ×2.0.

Preprocessing

Variable aperture, dynamic apodization, dynamic filtering and so on.

Postprocessing

Three kinds of images models are selectable, 8 kinds of γrectification, line coorelation, the dotted line correclation, linear interpolate, digital temporal filtering, digital mizobe enhancement. 16 kinds of pseudo-color processing etc.

Frequency conversion

2.5MHz, 3.0MHz,3.5MHz,4.0MHz

Gray Scale

256

Geometrical Precision

Vertical ≤5% Horizontal ≤10%

Focusing

1-, 2-, 3-, and 4-stage dynamic focusing for arbitrary option.

Measurements

Distance, area, volume, circumference, HR, pregnancy (BPD, GS,CRL,FLand AC) and fetal weight etc.

Note function

16 kinds of body marker of probe position, Full-screen character annotation, real-time clock display

Image Polarity

left/right turn, positive /negative and up / down turn

Gain range

8 segment TGC, the overall gain could be adjusted

Imaging dynamic frequency wave filtering

7 kinds of  dynamic frequency wave filtering with memory

Permanent storage

128

Cineloop

256

Output Interface

SVGA and PAL video signal, USB

Probe

R60

Vertical resolution

1mm
