Nominal gross pressure |
100 KN |
Direction of feeding plate |
Horizontal |
Layer Counting |
12 layers |
Distance between hot platens |
70mm |
Numbers of hot platens |
13 pcs |
Dimension of hot Platens |
2800×1340×38 mm |
Numbers of Cylinder |
2pcs |
Diameter of Cylinder |
Φ180 mm |
Stroke of Cylinder |
840 mm |
Pressurization |
≤6.3Mpa |
Empty Closing Time |
20S |
Low Pressure Pump Flowing |
About 140 L/min |
Power |
5.5 kw-4P |
Overall Dimensions |
4630×1340×2605mm |
Machine Weight |
About 6,300 Kg |
