Front Generator Wind Turbine

Detailed Product Description

wind generator equipment
1.CE proved+7 patents
2.high efficiency+small size
3.NO MOQ+wholesale price
4.professional factory

wind generator equipment

As a professional manufacturer of small-sized wind generator equipment,we can offer products from 500w-20kw wind turbine generator .



 They have the great features of high power efficiency ;low energy comsumption by the wind

turbine generator itself ;low start-up wind speed with the patented technology ;long life design

with easily installation and maintenance .



5kw wind generator equipment is well used in :

housing ;ships ;remote rural areas;telecommunication stations ,monitoring stations, water-pumping etc .



  The main technical datas of Hummer H6.4-5000w wind generator equipment is as bellowing :

Rated power(W)	5000
Maximum output powerW	7500
Charging voltage (V)	DC 240
Blade quantity	3
Rotor blade material	GRP
Rotor blade diameterm	6.4
Start-up wind speed (m/s)	2.5
Rated wind speed (m/s)	10.0
Rated rotating rate (r/min)	240
Wind energy utilizing ratio (Cp)	0.4
Generator output	Single-phase  frequency conversion AC
Rated charging current (A)	20
The maximum charging current (in a short time )(A)	32
Output AC frequency (Hz)	0~360
Generator efficiency	>0.8
Free standing tower diameter(mm)	495*185*12000 (2pcs)
Guy tower diameter(mm)	220*3000*6 (4pcs)
Tower height(m)	12
The weight of generator(kg)	147
Battery 12V 150Ah/200Ah	20pcs
