wind generator equipment
Main technical parameter
| Rated power (W) | 30000 |
| Maximum output power (W) | 45000 |
| Charging voltage (V) | DC 360 |
| Blade quantity | 3 |
| Rotor blade material | GRP |
| Rotor blade diameter (ft.) | 33 (10.0m) |
| Start-up wind speed (mph) | 6 (2.5m/s) |
| Rated wind speed (mph) | 25 (11.0m/s) |
| Rated rotating rate (r/min) | 160 |
| Wind energy utilizing ratio (Cp) | 0.42 |
| Generator output | Frequency conversion AC |
| Rated charging current (A) | 83 |
| The maximum charging current (in a short time ) (A) | 125 |
| Output AC frequency (Hz) | 0~400 |
| Generator efficiency | >0.92 |
| Free standing tower diameter (in.) | Φ47.2*Ø18.7 (Ø1200*Φ475mm) |
| Tower height (ft.) | 59 (18m) |
| The weight of generator (lb) | 1764 (800kg) |
| Suggested Battery (Ah) | 600/1000 |
