wind generator equipment
Features of hummer 5000W wind generator equipment:
1. SCF supercritical generator technology, generator weigh only 147kg, generation efficiency over 0.80.
2. Quality parts use SKF bearings and Siemens PLC control system and so on
3. Sine wave output, drive 2kw pump, 5kw appliances etc.
4. Use electric protection
5. Connect with 1500w solar panels to make up the wind solar hybrid system.
6. low energy comsumption by the wind turbine generator itself .
7. low start-up wind speed with the patented technology .
8. long life design with easily installation and maintenance .
Application of Model H6.4-5000W wind generator equipment:
It can drive air-condition (3-5 horsepower),
1.7KW water pump or other resistive appliances (≤5KW).
Well used in:
Housing and factory and farm
Telecommunication Station
TV Transfer Station
Monitoring Station (military, hydrology, observatory)
Water-pumping Station
shipping
The main technical datas of it is as bellowing :
Rated power(W) |
5000 |
Maximum output powerW |
7500 |
Charging voltage (V) |
DC 240 |
Blade quantity |
3 |
Rotor blade material |
GRP |
Rotor blade diameterm |
6.4 |
Start-up wind speed (m/s) |
2.5 |
Rated wind speed (m/s) |
10.0 |
Rated rotating rate (r/min) |
240 |
Wind energy utilizing ratio (Cp) |
0.4 |
Generator output |
Single-phase frequency conversion AC |
Rated charging current (A) |
20 |
The maximum charging current (in a short time )(A) |
32 |
Output AC frequency (Hz) |
0~360 |
Generator efficiency |
>0.8 |
Free standing tower diameter(mm) |
495*185*12000 (2pcs) |
Guy tower diameter(mm) |
220*3000*6 (4pcs) |
Tower height(m) |
12 |
The weight of generator(kg) |
147 |
Battery 12V 150Ah/200Ah |
20pcs |
