wind turbine



  • Products Visitors:4225
  • Product Name:wind turbine
  • Package:0.871 CBM, 7 Packages
  • Size:3.8m wind blades, 10m guyed tower
  • Model:H3.8-2KW



Detailed Product Description


wind energy turbine
1.CE proved+7 patents
2.high efficiency+small size
3.NO MOQ+wholesale price
4.professional factory

 Hummer 2kw wind energy turbine gives you a clear look how small Hummer wind generator is ,which is able to be placed inside nose cone .Though very small , compared with traditional turbine ,its stronger power making ability has won Hummer's reputation in market .Refined material ,strong structure and mature techniques ensure its toughness in wild filed .



  Due to its small size and light weight ,thus easy to carry ,it is a favor to people who often travel ,places that do not require high power supply ,like observation site ,military post and TV transimission station .



 The main technical of 2kw wind energy turbine is :

H3.8-2000W wind turbine Specifications
Configuration 3 Blades, Horizontal axis, Upwind
Rotor Diameter Ф3.8 m / 12.5 ft
Swept Area 11.35 m2 / 122.2 ft2
Direction of Rotation Clockwise looking upwind
Blade Material Fiberglass reinforced composite
Rated Power 2 kW @ 11m/s / 24.6 mph
Maximum Output Power 2.2 kW @ 20m/s / 44.7 mph
Battery Bank Voltage 120 Vdc
System Output Voltage 110/220 Vac
Cut-in Wind Speed 3 m/s / 6.7 mph
Rated rotating rate 450 r/min
Working Wind Speed 3-25 m/s / 6.7-82.2  mph
Survival Wind Speed 50 m/s / 164 mph
Alternator Permanent magnet alternator, SCF technology
Alternator Weight 25 kg / 55.1 lbs
Generator Efficiency >0.80
Wind Energy Utilizing Ratio 0.45 Cp
Energy monitoring & User control LED display
Gearbox None, Direct drive with front generator design
Over Speed Regulation Passive furling tail design
Shutting Down Method Manual & Automatic electromagnetism Braking
Warranty 2 years for generator and 1 year for other parts
