Wind-Solar Hybrid Light






Detailed Product Description


Wind-Solar Hybrid Light
1.CE proved+7 patents
2.high efficiency+small size
3.NO MOQ+wholesale price
4.professional factory

17



hybrid street light

1. SCF supercritical generator technology, generator weight only 6.5 kg, generator efficiency over 0.80.

2. High quality parts, SKF bearings and so on

3. Specially designed for wind-solar hybrid street light system

4. Hummer H1.25-400w wind-solar hybrid systemis specially designed for wind-solar

    hybrid street light system .

5. The fantastic solar-wind hybird street light is uses both solar and wind

    energy to generate essentially unlimited power.

6. The electromagnetic brake technique of H1.25-400W can provide high efficiency and safety .



Hybrid Light technical data of H1.25-400W wind solar hybrid system:

Rated power

400

Maximum output power

600

Charging voltage (v)

12V

Blade quantity

3

Blade material

Nylon

Blade diameter(m)

1.25

Start-up wind speed (m/s)

2.5

Rated wind speed (m/s)

11

Rated rotating rate (r/min)

800

Wind energy utilizing ratio (Cp)

0.4

Generator output

Single-phase frequency conversion AC

Output AC frequency(HZ)

0-300

Rated charging current (A)

33.3

The maximum charging current (in a short time)(A)

45

Generator efficiency

>0.8

Tower diameter (mm)

65

Tower height(m)

9

weight of generator(kg)

5.5

Suggested Battery

100/120 Ah



For more details  ,pls feel free to contact with us .we also supply other kind of street light,such as solar light, wind street light,solar street light,solar outdoor light etc.
