Front Generator Wind Turbine

Detailed Product Description

wind energy turbine
1.CE proved+7 patents
2.high efficiency+small size
3.NO MOQ+wholesale price
4.professtional factory

wind energy turbine

Hummer 500w wind energy turbine output single-phase frequency conversin AC,It has the features of high power efficiency ;low start-up wind speed at 3m/s ;reliable protection of over current /temperature/loading /short circuit etc ;long life design.

 The main technical datas of hummer 500w wind turbine windmill:

Rated power(W)	500
Maximum output powerW	1000
Charging voltage (V)	DC 24
Blade quantity	3
Blade material	GRP
Blade diameterm	2.7
Start-up wind speed (m/s)	3.0
Rated wind speed (m/s)	7.0
Rated rotating rate  (r/min)	600
Wind energy utilizing ratio (Cp)	0.48
Generator output	Single-phase frequency conversion AC
Output AC frequency (Hz)	0~300
Rated charging current (A)	15
The maximum charging current (in a short time )(A)	25
Generator efficiency	>0.78
Tower diameter(mm)	76*2000*3 (3pcs)
Tower height(m)	6
Generator weight (kg)	6.5
Battery 12V 150Ah/200Ah	2pcs
