small wind turbine
Application of Model H8.0-10000W small wind turbine:
It can drive air-condition (8-10 horsepower), 3kw water pump or other resistive appliances (≤10KW)
Well used in:
|
Rated power(W) |
10000 |
|
Maximum output power(W) |
15000 |
|
Charging voltage (V) |
DC 240 |
|
Blade quantity |
3 |
|
Rotor blade material |
GRP |
|
Rotor blade diameter(m) |
8.0 |
|
Start-up wind speed (m/s) |
3.0 |
|
Rated wind speed (m/s) |
10.0 |
|
Rated rotating rate (r/min) |
200 |
|
Wind energy utilizing ratio (Cp) |
0.4 |
|
Generator output |
Single-phase frequency conversion AC |
|
Rated charging current (A) |
41.7 |
|
The maximum charging current (in a short time )(A) |
65 |
|
Output AC frequency (Hz) |
0~280 |
|
Generator efficiency |
>0.8 |
|
Free standing tower diameter(mm) |
900*630*15000 (2pcs) |
|
Guy tower diameter(mm) |
1050*750 *16000(2pcs) |
|
Tower height(m) |
15 |
|
The weight of generator(kg) |
287 |
|
Battery 12V 600Ah/800Ah |
20pcs |
