Front Generator Wind Turbine

Detailed Product Description

wind turbine for home
1.CE proved+7patents
2.high efficiency+small size
3.NO MOQ+wholesale price
4.professional factory



wind turbine for home



Features of hummer 500W wind turbines:

1. SCF supercritical generator technology, generator weight only 6.5 kg, generator efficiency over 0.78.

2. Quality parts use SKF bearings and so on

3. Sine wave output, drive water pump (< 370w), refrigerator (<130L) etc.

4. High cost performance

5. Low running noise

6. Connect with 300W solar panels to make up the wind-solar hybrid system.



Application of Model H2.7-500W wind turbine

It can drive color TV, refrigerator (<=130L), pump (<=370W) or other resistive appliances (<500W).   Well used in:

  Housing, office, farm and factory

 Telecommunications Station

 TV Transfer Station

 Monitoring Station (military, hydrology, observatory)

 Water-pumping Station



Main technical data

Rated power (W)	500
Maximum output power (W)	1000
Charging voltage (V)	DC 24
Blade quantity	3
Blade material	GRP
Blade diameter (ft.)	9   (2.7m)
Start-up wind speed (mph)	7   (3.0m/s)
Rated wind speed (mph)	16 (7.0m/s)
Rated rotating rate  (r/min)	600
Wind energy utilizing ratio (Cp)	0.48
Generator output	Frequency conversion AC
Output AC frequency (Hz)	0-300
Rated charging current (A)	16.7
The maximum charging current (in a short time)(A)	25
Generator efficiency	>0.78
Tower diameter (in.)	3.0*78.7*0.1  (76*2000*3 mm)(3pcs)
Tower height (ft.)	20  (6m)
Generator weight (lb)	14  (6.5kg)
Suggested Battery (Ah)	120/150
