Front Generator Wind Turbine

Detailed Product Description
battery based wind turbine generator 30kw
1.higher generating efficiency above 0.92
2.lower start up wind speed 2.5m/s.

 Technical data of H10.0-30kw off-grid system

H10.0-30KW Specifications
Configuration	3 Blades, Horizontal axis, Upwind
Rotor Diameter	Ф10.0 m / 32.8 ft
Swept Area	78.54 m2 / 845.4 ft2
Direction of Rotation	Clockwise looking upwind
Blade Material	Fiberglass reinforced composite
Rated Power	30 kW @ 11m/s / 24.6 mph
Maximum Output Power	33 kW @ 20m/s / 44.7 mph
Battery Bank Voltage	360 Vdc
System Output Voltage	380 Vac
Cut-in Wind Speed	3 m/s / 6.7 mph
Rated rotating rate	160 r/min
Working Wind Speed	3-25 m/s / 6.7-82.7  mph
Survival Wind Speed	50 m/s / 164 mph
Alternator	Permanent magnet alternator, SCF technology
Alternator Weight	824 kg / 1816.6 lbs
Generator Efficiency	>0.92
Wind Energy Utilizing Ratio	0.42 Cp
Energy monitoring & User control	Siemens PLC controller with touch screen
Gearbox	None, Direct drive with front generator design
Over Speed Regulation	Auto Yawing & Hydraulic Braking
Shutting Down Method	Manual & Automatic electromagnetism Braking & Hydraulic Braking
Warranty	2 years for generator and 1 year for other parts
