9.0-20KW generator






Detailed Product Description


wind power turbine
1.CE proved+7 patents
2.high efficiency+small size
3.NO MOQ+wholesale price
4.professional factory

  Hummer 20kw wind power turbine output single-phase frequency conversin AC,It has the features of high power efficiency ;low start-up wind speed at 3m/s ;reliable protection of over current /temperature/loading /short circuit etc ;long life design.



20kw wind power turbine can drive air-condition ( <=20 horsepower), pump or other electrical appliances (<=20KW).

Well used in:

Housing

Telecommunication Station

TV Transfer Station

Monitoring Station (military, hydrology, observatory)

Water-pumping Station



Main technical parameter

Rated power(W)
20000
Maximum output power(W)
28000
Charging voltage (V)
DC 240
Blade quantity
3
Rotor blade material
GRP
Rotor blade diameter (ft.)
30  (9.0m)
Start-up wind speed (mph)
7    (3.0m/s)
Rated wind speed (mph)
26  (11.5m/s)
Rated rotating rate (r/min)
180
Wind energy utilizing ratio (Cp)
0.40
Generator output
Frequency conversion AC
Rated charging current (A)
83.3
The maximum charging current (in a short time) (A)
120
Output AC frequency (Hz)
0~320
Generator efficiency
>0.87
Free standing tower diameter (in.)
41.3*29.5 (1050*750mm)
 (2 segment)
Tower height (ft.)
52  (16m)
The weight of generator(lb)
1093  (496kg)
Suggested Battery (Ah)
800/1000
