Image Compression
|
H.264
|
Audio Compression
|
ADPCM
|
Operation System
|
Embedded Linux,with IR remote controller. Support remote view with Mobile Phones (based on Windows Mobile and Symbian S60, iPhone,Blackberry &Android operation system)
|
Resolution
|
Display(D1):704*576(PAL),704*480(NTSC)
Record(CIF):352*288(PAL),320*240(NTSC)
|
Rate
|
400fps(PAL),480fps(NTSC)
|
Operation Interface
|
Support USB mouse,Panel button,and remote controller
|
Hard Disk(HD)
|
Support up to 2 SATA hard disks of more than 4000GB capacity
|
VGA Output
|
YES
|
Record mode
|
Manual,timing,alarm,motion detection
|
Record search
|
Time,event,channel,diary search
|
Record save
|
Local hard disk,network
|
Backup mode
|
Network,USB,SATA hard disk record backup
|
Video input
|
16CH BNC
|
Video output
|
1CH BNC,1CH VGA output
|
Audio input
|
4CH RCA
|
Audio output
|
1CH RCA,and 1CH interphone
|
Alarm input
|
4CH
|
Alarm output
|
1CH
|
Image control
|
6 grade adjustable
|
Motion detection
|
Yes
|
Local playback
|
1CH--16CH playback simultaneously
|
Network
|
RJ45,10M/100M self adaptive Ethernet port
|
USB interface
|
2 USB2.0 high speed interface
|
Power Adapter
|
DC12V, 4A
|
Support languages
|
14 kinds languages: English,Simplified Chinese,Traditional Chinese(Big5),Portuguese,Spanish,Turkish,Hungarian,French,German,Polish,Italian, Russian,Japanese,Thai
|
