Model

MC1

MC2

MC3

Order#

484-131

484-132

484-123

Color type

Color

Color

Color

Pickup device

1/3''(6mm)

1/3''(6mm)

1/2''(8mm)

Horizontal Resolution TVL

540TV Line

480TV Line

480TV Line

Pixel HxV

752(H) x 582(V)

752(H) x 582(V)

752(H) x 582(V)

Minimun illumination

0.5Lux/F1.2

0.5Lux/F1.2

0.5Lux/F1.2

Backlight compensation

ON/OFF(Switchable)

ON/OFF(Switchable)

ON/OFF(Switchable)

AGC

ON/OFF(Switchable)

ON/OFF(Switchable)

ON/OFF(Switchable)

White balance

ON/OFF(Switchable)

ON/OFF(Switchable)

ON/OFF(Switchable)

Electronic shutter

1/50(1/60) ~ 1/100,000 sec

1/60 ~ 1/100,000 sec

1/50 ~ 1/100,000 sec

Gamma correction

0.45(on)/1(off)

0.45(on)/1(off)

0.45(on)/1(off)

S/N ratio

.>52dB

.>50dB

.>57dB

Signal Mode

PAL

PAL

PAL

Lens mount

C/CS

C/CS

C/CS

Power Supply

AC24/DC12V

AC24/DC12V

AC24/DC12V

Dimension(WxHxL)mm

59x58x133

35.5x36x64

70x57x260

 Net Weight

Approx.370g

Approx.90g

 Approx.550g

Operation Temperature

-10°C ~ +50°C

-10°C ~ +50°C

-10°C ~ +50°C

Storage Temperature

-40°C ~ +60°C

-40°C ~ +60°C

-40°C ~ +60°C
