Zhejiang DK Valve Co.,Ltd

We are a manufacture which is specialized in exporting Pneumatic Actuator to all of the world, there are many Pneumatic Actuator Valve trading companies in China, that's why we have to supply the best price and quality to become competitive in Rack Pneumatic Actuator industry. Welcome to inquire about our Pinion Pneumatic Actuator online!

Product Description
VS series pneumatic actuators (rack& pinion) have the following features.
> 15 actuator models, the output torque from 9NM to 4620Nm at 6 bar air supply.
> Bottom drilling complies with ISO5211/DIN3337 to match valve, interface for solenoid valve, shaft top end and top drilling for assembling accessories are in accordance with VDI/VDE3845 (Namur) standard and +/- 5 degree stroke adjustment.

> The actuator body & piston are over 20um hard anodized treatment and over 100um epoxy coated on end caps which meet ASTM B117 qualification, over 500 hours salt spread test, no corrosion on actuator.
> The end cap can be blue, black, grey, yellow etc. As your request.
> PTFE, Nickel, Epoxy, Polyester and Ceramic coated against corrosive & abrasive environment are available
