When a traffic accident occurs, how to judge the responsibilities ?
When driving outside for sightseeing, is there any easy way for the user to record those beautiful scenes?
Since exciting moments happen around us from time to time, is there any easy way to capture them?
car black box is aiming to solve all of them.

Highlights
1.Considerate design, stable performance. The device can work continuously for more than 2 weeks without any problems.
2.Excellent image quality, competitive with those professional digital camcorders.
3.Very professional and dedicated to in-car use.
4.Neat and beautiful appearance. It's easy to install and operate.
5.Very fast boot performance, supreme auto exposure convergence and rapid movie recording.

Feature

>Image Quality:Great and very impressive.The proprietary built-in auto exposure, auto white balance algorithms and sophisticated image signal processing technologies bring up the finest image quality under most of circumstances.

>Overlapped Seamless Record:Supported. There is no frame drop. In addition, the overlapped period between two adjacent clips can be configured as either 0, 1 second or 2 seconds.

>Uninterrupted Power Supply:Supported. Due to the physical characteristics of lithium-ion battery, it may cause self-ignition under high-temperature circumstance. In CSG168, we don't use built-in li-ion battery at all. Instead, we adopt two super capacitors to maintain the power supply for several seconds. Our real-time algorithm on power supply monitor enables CSG168 to detect the external power cut-off terminate end the movie recording in time. No corrupted movie clip.

Parameter

◆Power Supply:Vehicle cigarette lighter, 12V ~ 24V DC
◆Image Sensor:High-Sensitivity CMOS Image Sensor
◆Lens:110 degree diagonal field of view
◆Display Device:2.7 TFT LCD, 24-bit Color
◆MIC:Built-in MIC
◆Speaker:Built-in speaker
◆A/V output:One port, composite video broadcast signal (CVBS) plus line-out
◆Video Resolution:1280 x 720 (HD), 30fps
◆Video Compression:H.264 / MPEG4-AVC
◆Audio:16-bit Mono, FS = 48KHz, AAC compression
◆Bit Rate:7Mbps, or 0.875MB/Sec
◆File Type:MP4
◆Media:SD/SDHC card, 256MB ~ 32GB
◆Digital Zoom:Supported, Up to 4.0x
◆Auto Record on Car Start:Supported
◆Movie Clip Duration:Configurable, from 1 minute ~ 5 minutes
◆Date/time Imprint:Supported. Its format is, YYYY/MM/DD HH:MM:SS. For example 2011/02/02 08:12:24
◆Cyclic Record:Supported. The oldest movie clips will be erased when the media turns to be full during recording
◆User Interface:Simple, friendly and pragmatic
◆Multi-lingual:English, Chinese Traditional, Chinese Simple
