power supply
| Model No. | ACB-PS08. |
| Product Name | Power Supply |
| Basic Info | |
| Unit Size | 273mm*228mm*65mm |
| Unit Packing Way | BOX |
| Accessories | User Manual, warranty card |
| FEATURES ACB-PS08 works for ACB-R01.ACB-R02.ACB-RO4,ACB- T01.ACB-T02.ACB-T04 | |
| power transformer | 30-50W High power transformer ,with higher efficiency, big output power for work with 2-4 card readers +1 controller+4 pcs Electronic Locks or 3 pcs magnetic lock with 280Kg |
| thermal exhaust | With standard thermal exhaust design. All metal design, good anti-interference and thermal exhaust. | ||||||||||||
| the cover | Cover can be removed and fitted buckle, with standard PVC pipe, and 5 | ||||||||||||
| Gourd-shaped hooks inside of case. | |||||||||||||
| the fuse | Power has 5A fuse in front-end and back-end, with protective circuit in case damage by short-circuit. And convenient to change new fuse the corresponding fuse has prompted lights. | ||||||||||||
| inside of case | Inside of case with Ground connection point design for lightning protection, anti-static and anti-Surge | ||||||||||||
| wiring space | Sufficient space for wiring, Pull out terminal blocks. | ||||||||||||
| battery depletion protection | Protection for battery depletion, If the rechargeable battery exhausted, the battery will damage and obsolescence,If without the protection for exhaust ,will result in a critical state, invalid for read card ,power locked,user will locked up until the power supply runs out or reset. | ||||||||||||
| charge | With Charge and discharge function, can circumscribed battery with 7AH 12VDC to support 3-5 hours work with 1pc electronic lock ,1 pc card reader,1 pc controller . | ||||||||||||
|
|||||||||||||
