| Specification | ||||
| Minimum Power Tolerance | +-3% | |||
| Cell Mono-crystalline | 125*125mm | |||
| No.of cells and connections | 72 in series | |||
| Weight | 15KG | |||
| Module size | 1580*808*50mm | |||
| Temperature Coefficient | ||||
| NOCT | 45+-2 | |||
| Voltage Temp Coeffcient | -0.33% | |||
| Current Temp Coeffcient | +0.05% | |||
| Power Temp Coeffcient | -0.23% | |||
| Electrical Characteristics | ||||
| Module Type | SD-160W | |||
| Nominal Peak Power(Pmax) | 160W | |||
| Nominal Voltage(Vmp) | 34.56V | |||
| Nominal Current(Imp) | 4.45A | |||
| Open Circuit Voltage(Voc) | 42V | |||
| Short Circuit Current(Isc) | 5.07 | |||
| Module Efficiency | 15.00% | |||
| Operating Temperature | -40 to+85 | |||
| Maximum System Voltage | 1000V DC | |||
