Model

 SD-SP027

Ratin power (Pm)

 90W

Cells

 Mono crystal 125mmx125mm square

 Number of cells

36 (4x9) series connected

Size

 1200 (L) x 550(W) x35(H) mm

 Weight

7.8Kg

Typical application

 12V DC

 Maximum voltage

 1000V DC

 Operating temperature

 45 degree

 Hail diameter @ 80Km/h

 Up to 25 mm

 Continuous wind pressure

 Up to 24 m/s

 Efficiency of cell

 >16.45%

Tolerance

 +/-3%

 Rated current (Im)

 5.00A

 Rated voltage(Vm)

 18.0V

Short circuit Current(Isc)

5.29A

 Open circuit Voltage(Voc)

 22.4V
